Input parameters: Three phase, AC380V±10%,50HZ
Output parameters: DC 0~15V 0~1KA
Output mode: Common DC output
Cooling method: Forced air cooled or water cooled
Power supply type: IGBT-based
Application Industry: For gold, silver, nickel, zinc, tin, rhodium, chromium and other rare metals electroplating, precision patterns, precious jewelry electroplating, electrolytic polishing, anodizing industry which have strict and high requirements on treatment.
PCB electroplating power supply mainly includes high-frequency switching power supply, single pulse power supply, high-speed positive and negative pulse power supply, mainly pulse power supply and high-precision DC power supply. The market share of PCB electroplating power supply reaches 75%. Over the years, We have maintained good communication with high-end equipment manufacturers, brand potion manufacturers and end users. Many new technologies have been developed to improve the process quality and efficiency of PCB manufacturing from the aspects of power supply and equipment.
Liyuan PCB power supply has the comprehensive advantages of stable performance (sealing and structure), high efficiency (the highest efficiency can exceed 94%), high control precision, small size, all-new installation mode to reduce costs, improve electroplating uniformity, and optimize electroplating process.
In the PCB manufacturing process, electroless copper plating is an important step. It is widely used in the following two processes. One is plating onto bare laminate and the other is plating through hole, because under these two circumstances, electroplating cannot or can hardly be carried out. In the process of plating onto bare laminate, electroless copper plating plates a thin layer of copper on the bare substrate to make the substrate conductive for further electroplating. In the process of plating through hole, electroless copper plating is used to make the inner walls of the hole conductive to connect the printed circuits in different layers or the pins of the integrated chips.
Manufacturers widely use electroplating rectifier equipment for various surface treatment applications, including PCB electroplating, hard chrome coating, copper plating, nickel plating, zinc plating, gold plating, tin plating, and silver plating, among other metal finishing.
1)Field application diagram:

2)Industry application examples:

› RS485 digital control function
› High power factor and high efficiency
› Reasonable structural design
› Only the radiator is in the air duct
› Effective sealing and isolation
› High protective properties
› Standard wiring and special wiring
› Practical and effective multiple protection system
› Full soft switching technology
› High reliability
| Input voltage | Three phase AC380V/440Vac±10%, 50-60HZ Single phase AC220±10% |
| Adjustable frequency duty cycle | Operation time t1:1ms-999ms On-off time t2: 1ms-999ms |
| Voltage regulation precision | ≤1% |
| Current regulation precision | ≤1% |
| Rated efficiency | ≥90% |
| Operation environment | -10-40℃ |
| Storage temperature | -20-50℃ |
| Insulation strength | Input-output: AC1500V, 10mA, 1 min |
| Input-shell: AC1000V, 10mA, 1 min | |
| Cooled mode | Forced air cooled or water cooled |
| Operation conditions | 24-hour operation under full load |
| Output voltage range | 0-15V |
| Output current range | 0-1000A |
| *Ok to customize as per requirements* | |
If you need other pulse power supplies, we can custom design them according to customer requirements. Please contact us.
Seeking a 15V 1000A pulse plating rectifier? Liyuan Haina Group is one of the professional manufacturers and suppliers in this field. With over 27 years of focus on R&D, design, production, sales, and technical services for industrial rectifiers, we have already exported our products to the United States, Canada, Britain, Italy, Spain, South Africa, Russia, the UAE, Japan, South Korea, Malaysia, and other parts of the world. Equipped with a productive factory, we warmly welcome you to purchase our high-quality, Made-in-China products at competitive prices or try our customized service.
