Input parameters: Three phase, AC380V±10% ,50~60HZ

Output parameters: DC +50V +50KA , -50V -50KA

Output mode: Polarity reversing

Cooling method: Water cooling

Power supply type: Silicon controlled rectifier

Application Industry: Wastewater treatment

• Automatic polarity reverse broadly avoid the trouble operation to reverse by manual.
• Positive and negative reverse time can be set
• The positive and negative independent regulation Single/cycling selecting function
• Positive and negative auto-reverse function
• Both Voltage and current regulated control mode
• Over-pressure, over-current, phase failure and over -heat protection function.
• 12-pulse band filter reactor is used to improve output ripple wave.
• RS484 interface and digital network control are optional.

The current application of wastewater treatment mainly includes reclaimed water reuse; Industrial waste water reuse; Detoxification treatment of raw water in factory culture; Power plant, chemical plant and other large cooling circulating water side filtration system; Oilfield produced water reuse treatment; Treatment of emulsion waste liquid of steel rolling; Metal surface cleaning liquid regeneration treatment.

Liyuan wastewater treatment power supply can be widely used in various wastewater treatment processes, such as electrocoagulation of electroplating wastewater, electroadsorption, micro-electrolysis technology, and the removal of heavy metals electrolytic precipitation or floating, membrane electrolysis, electrodialysis and ion exchange method.
