Input parameters: Single phase, AC220V±10% ,50HZ
Output parameters: DC 0~5V 0~30A
Output mode: Common DC output
Cooling method: Water cooling
Power supply type: IGBT-based power supply
Application Industry: Plating industry
Characteristic Types |
Parameter Items |
Technical Requirements |
| Power Types | Power types | High-frequency Power Supply |
| Model and specifications | TBSBZ-30A/5V | |
| Cooling mode | Water-cooled | |
| Switch tube type | IGBT | |
| Input Characteristics | Rated Input Voltage | Single phase, AC220V±10% ,50HZ |
| Rated Input Power | 0.17KVA | |
| Rated Input Current | AC 0.26A | |
| Input Power Factor | COSΦ≥0.95 | |
| Output Characteristics | Output Voltage | DC 0～5V |
| Output Current | DC 0～30A | |
| Stabilized Current Precision | ≤1%（Rated Current) | |
| According to accuracy | 0.1A，0.01V | |
| Rated Output efficiency | ≥91% | |
| Environmental Conditions | Installation site | Indoor installations |
| Altitude | ≤2000 meters | |
| Ambient temperature | -20℃～40℃ | |
| Relative humidity | ≤90％ | |
| Control Mode | Operating mode | PLC, ADDA, Ethernet, RS485 and RS232 |
| Weight | Net weight | About 16KG |
| External Dimension | Height*Width*Depth | H247mm×W100mm×D378mm |
| Protection Characteristics | With over voltage, over current, overload, short circuit, overheating and other abnormal self-protection function | |
| Application | Model | Output Parameters |
| 220V Single phase input | TBFB-50A9V | 9Vdc/50A |
| HMFB-5A12V | 12Vdc/5A | |
| TBFBZ-10A12V | 12Vdc/10A | |
| HMFB-20A12V | 12Vdc/20A | |
| HMFB-150A12V | 12Vdc/150A | |
| TBFA-30A12V | ±12Vdc/30A | |
| HMFB-30A12V | 12Vdc/30A | |
| HMFB-50A12V | 12Vdc/50A | |
| HMFB-100A12V | 12Vdc/100A | |
| HMFB-150A12V | 12Vdc/150A | |
| TBFBZ-2200A12V | 12Vdc/2200A | |
| HMFB-20A15V | 15Vdc/20A | |
| HMFB-100A15V | 15Vdc/100A | |
| HMFB-50A20V | 20Vdc/50A |
